涨知识了，Linux的ld和ldd一起用，可以帮我们分析运行时加载库文件失败的原因
创始人
2025-07-11 15:40:29
0次

很多时候，开发人员/运维人员需要处理软件运行时报错找不到依赖库的问题，除了可以通过strace、gdb等工具跟踪启动加载的过程获得依赖库信息，还可以通过本文介绍的 ld + ldd 命令，帮助分析。

这里以分析 libmpi_usempif80.so 这个动态库文件，依赖哪些其他动态库，作为问题起因。

首先介绍 ld 命令如何帮我们分析mpi_usempif80 库依赖其他哪些库？mpi_usempif80 库被加载时，会从当前系统的哪些路径下搜索这些库？

#ld -lmpi_usempif08 --verbose

GNU ld (GNU Binutils for Ubuntu) 2.38
  Supported emulations:
   elf_x86_64
   elf32_x86_64
   elf_i386
   elf_iamcu
   elf_l1om
   elf_k1om
   i386pep
   i386pe
using internal linker script:
==================================================
/* Script for -z combreloc -z separate-code */
/* Copyright (C) 2014-2022 Free Software Foundation, Inc.
   Copying and distribution of this script, with or without modification,
   are permitted in any medium without royalty provided the copyright
   notice and this notice are preserved.  */
OUTPUT_FORMAT("elf64-x86-64", "elf64-x86-64",
       "elf64-x86-64")
OUTPUT_ARCH(i386:x86-64)
ENTRY(_start)
SEARCH_DIR("=/usr/local/lib/x86_64-linux-gnu"); SEARCH_DIR("=/lib/x86_64-linux-gnu"); SEARCH_DIR("=/usr/lib/x86_64-linux-gnu"); SEARCH_DIR("=/usr/lib/x86_64-linux-gnu64"); SEARCH_DIR("=/usr/local/lib64"); SEARCH_DIR("=/lib64"); SEARCH_DIR("=/usr/lib64"); SEARCH_DIR("=/usr/local/lib"); SEARCH_DIR("=/lib"); SEARCH_DIR("=/usr/lib"); SEARCH_DIR("=/usr/x86_64-linux-gnu/lib64"); SEARCH_DIR("=/usr/x86_64-linux-gnu/lib");
SECTIONS
{
  PROVIDE (__executable_start = SEGMENT_START("text-segment", 0x400000)); . = SEGMENT_START("text-segment", 0x400000) + SIZEOF_HEADERS;
  .interp         : { *(.interp) }
  .note.gnu.build-id  : { *(.note.gnu.build-id) }
  .hash           : { *(.hash) }
  .gnu.hash       : { *(.gnu.hash) }
  .dynsym         : { *(.dynsym) }
  .dynstr         : { *(.dynstr) }
  .gnu.version    : { *(.gnu.version) }
  .gnu.version_d  : { *(.gnu.version_d) }
  .gnu.version_r  : { *(.gnu.version_r) }
  .rela.dyn       :
    {
      *(.rela.init)
      *(.rela.text .rela.text.* .rela.gnu.linkonce.t.*)
      *(.rela.fini)
      *(.rela.rodata .rela.rodata.* .rela.gnu.linkonce.r.*)
      *(.rela.data .rela.data.* .rela.gnu.linkonce.d.*)
      *(.rela.tdata .rela.tdata.* .rela.gnu.linkonce.td.*)
      *(.rela.tbss .rela.tbss.* .rela.gnu.linkonce.tb.*)
      *(.rela.ctors)
      *(.rela.dtors)
      *(.rela.got)
      *(.rela.bss .rela.bss.* .rela.gnu.linkonce.b.*)
      *(.rela.ldata .rela.ldata.* .rela.gnu.linkonce.l.*)
      *(.rela.lbss .rela.lbss.* .rela.gnu.linkonce.lb.*)
      *(.rela.lrodata .rela.lrodata.* .rela.gnu.linkonce.lr.*)
      *(.rela.ifunc)
    }
  .rela.plt       :
    {
      *(.rela.plt)
      PROVIDE_HIDDEN (__rela_iplt_start = .);
      *(.rela.iplt)
      PROVIDE_HIDDEN (__rela_iplt_end = .);
    }
  .relr.dyn : { *(.relr.dyn) }
  . = ALIGN(CONSTANT (MAXPAGESIZE));
  .init           :
  {
    KEEP (*(SORT_NONE(.init)))
  }
  .plt            : { *(.plt) *(.iplt) }
.plt.got        : { *(.plt.got) }
.plt.sec        : { *(.plt.sec) }
  .text           :
  {
    *(.text.unlikely .text.*_unlikely .text.unlikely.*)
    *(.text.exit .text.exit.*)
    *(.text.startup .text.startup.*)
    *(.text.hot .text.hot.*)
    *(SORT(.text.sorted.*))
    *(.text .stub .text.* .gnu.linkonce.t.*)
    /* .gnu.warning sections are handled specially by elf.em.  */
    *(.gnu.warning)
  }
  .fini           :
  {
    KEEP (*(SORT_NONE(.fini)))
  }
  PROVIDE (__etext = .);
  PROVIDE (_etext = .);
  PROVIDE (etext = .);
  . = ALIGN(CONSTANT (MAXPAGESIZE));
  /* Adjust the address for the rodata segment.  We want to adjust up to
     the same address within the page on the next page up.  */
  . = SEGMENT_START("rodata-segment", ALIGN(CONSTANT (MAXPAGESIZE)) + (. & (CONSTANT (MAXPAGESIZE) - 1)));
  .rodata         : { *(.rodata .rodata.* .gnu.linkonce.r.*) }
  .rodata1        : { *(.rodata1) }
  .eh_frame_hdr   : { *(.eh_frame_hdr) *(.eh_frame_entry .eh_frame_entry.*) }
  .eh_frame       : ONLY_IF_RO { KEEP (*(.eh_frame)) *(.eh_frame.*) }
  .gcc_except_table   : ONLY_IF_RO { *(.gcc_except_table .gcc_except_table.*) }
  .gnu_extab   : ONLY_IF_RO { *(.gnu_extab*) }
  /* These sections are generated by the Sun/Oracle C++ compiler.  */
  .exception_ranges   : ONLY_IF_RO { *(.exception_ranges*) }
  /* Adjust the address for the data segment.  We want to adjust up to
     the same address within the page on the next page up.  */
  . = DATA_SEGMENT_ALIGN (CONSTANT (MAXPAGESIZE), CONSTANT (COMMONPAGESIZE));
  /* Exception handling  */
  .eh_frame       : ONLY_IF_RW { KEEP (*(.eh_frame)) *(.eh_frame.*) }
  .gnu_extab      : ONLY_IF_RW { *(.gnu_extab) }
  .gcc_except_table   : ONLY_IF_RW { *(.gcc_except_table .gcc_except_table.*) }
  .exception_ranges   : ONLY_IF_RW { *(.exception_ranges*) }
  /* Thread Local Storage sections  */
  .tdata   :
   {
     PROVIDE_HIDDEN (__tdata_start = .);
     *(.tdata .tdata.* .gnu.linkonce.td.*)
   }
  .tbss    : { *(.tbss .tbss.* .gnu.linkonce.tb.*) *(.tcommon) }
  .preinit_array    :
  {
    PROVIDE_HIDDEN (__preinit_array_start = .);
    KEEP (*(.preinit_array))
    PROVIDE_HIDDEN (__preinit_array_end = .);
  }
  .init_array    :
  {
    PROVIDE_HIDDEN (__init_array_start = .);
    KEEP (*(SORT_BY_INIT_PRIORITY(.init_array.*) SORT_BY_INIT_PRIORITY(.ctors.*)))
    KEEP (*(.init_array EXCLUDE_FILE (*crtbegin.o *crtbegin?.o *crtend.o *crtend?.o ) .ctors))
    PROVIDE_HIDDEN (__init_array_end = .);
  }
  .fini_array    :
  {
    PROVIDE_HIDDEN (__fini_array_start = .);
    KEEP (*(SORT_BY_INIT_PRIORITY(.fini_array.*) SORT_BY_INIT_PRIORITY(.dtors.*)))
    KEEP (*(.fini_array EXCLUDE_FILE (*crtbegin.o *crtbegin?.o *crtend.o *crtend?.o ) .dtors))
    PROVIDE_HIDDEN (__fini_array_end = .);
  }
  .ctors          :
  {
    /* gcc uses crtbegin.o to find the start of
       the constructors, so we make sure it is
       first.  Because this is a wildcard, it
       doesn't matter if the user does not
       actually link against crtbegin.o; the
       linker won't look for a file to match a
       wildcard.  The wildcard also means that it
       doesn't matter which directory crtbegin.o
       is in.  */
    KEEP (*crtbegin.o(.ctors))
    KEEP (*crtbegin?.o(.ctors))
    /* We don't want to include the .ctor section from
       the crtend.o file until after the sorted ctors.
       The .ctor section from the crtend file contains the
       end of ctors marker and it must be last */
    KEEP (*(EXCLUDE_FILE (*crtend.o *crtend?.o ) .ctors))
    KEEP (*(SORT(.ctors.*)))
    KEEP (*(.ctors))
  }
  .dtors          :
  {
    KEEP (*crtbegin.o(.dtors))
    KEEP (*crtbegin?.o(.dtors))
    KEEP (*(EXCLUDE_FILE (*crtend.o *crtend?.o ) .dtors))
    KEEP (*(SORT(.dtors.*)))
    KEEP (*(.dtors))
  }
  .jcr            : { KEEP (*(.jcr)) }
  .data.rel.ro : { *(.data.rel.ro.local* .gnu.linkonce.d.rel.ro.local.*) *(.data.rel.ro .data.rel.ro.* .gnu.linkonce.d.rel.ro.*) }
  .dynamic        : { *(.dynamic) }
  .got            : { *(.got) *(.igot) }
  . = DATA_SEGMENT_RELRO_END (SIZEOF (.got.plt) >= 24 ? 24 : 0, .);
  .got.plt        : { *(.got.plt) *(.igot.plt) }
  .data           :
  {
    *(.data .data.* .gnu.linkonce.d.*)
    SORT(CONSTRUCTORS)
  }
  .data1          : { *(.data1) }
  _edata = .; PROVIDE (edata = .);
  . = .;
  __bss_start = .;
  .bss            :
  {
   *(.dynbss)
   *(.bss .bss.* .gnu.linkonce.b.*)
   *(COMMON)
   /* Align here to ensure that the .bss section occupies space up to
      _end.  Align after .bss to ensure correct alignment even if the
      .bss section disappears because there are no input sections.
      FIXME: Why do we need it? When there is no .bss section, we do not
      pad the .data section.  */
   . = ALIGN(. != 0 ? 64 / 8 : 1);
  }
  .lbss   :
  {
    *(.dynlbss)
    *(.lbss .lbss.* .gnu.linkonce.lb.*)
    *(LARGE_COMMON)
  }
  . = ALIGN(64 / 8);
  . = SEGMENT_START("ldata-segment", .);
  .lrodata   ALIGN(CONSTANT (MAXPAGESIZE)) + (. & (CONSTANT (MAXPAGESIZE) - 1)) :
  {
    *(.lrodata .lrodata.* .gnu.linkonce.lr.*)
  }
  .ldata   ALIGN(CONSTANT (MAXPAGESIZE)) + (. & (CONSTANT (MAXPAGESIZE) - 1)) :
  {
    *(.ldata .ldata.* .gnu.linkonce.l.*)
    . = ALIGN(. != 0 ? 64 / 8 : 1);
  }
  . = ALIGN(64 / 8);
  _end = .; PROVIDE (end = .);
  . = DATA_SEGMENT_END (.);
  /* Stabs debugging sections.  */
  .stab          0 : { *(.stab) }
  .stabstr       0 : { *(.stabstr) }
  .stab.excl     0 : { *(.stab.excl) }
  .stab.exclstr  0 : { *(.stab.exclstr) }
  .stab.index    0 : { *(.stab.index) }
  .stab.indexstr 0 : { *(.stab.indexstr) }
  .comment       0 : { *(.comment) }
  .gnu.build.attributes : { *(.gnu.build.attributes .gnu.build.attributes.*) }
  /* DWARF debug sections.
     Symbols in the DWARF debugging sections are relative to the beginning
     of the section so we begin them at 0.  */
  /* DWARF 1.  */
  .debug          0 : { *(.debug) }
  .line           0 : { *(.line) }
  /* GNU DWARF 1 extensions.  */
  .debug_srcinfo  0 : { *(.debug_srcinfo) }
  .debug_sfnames  0 : { *(.debug_sfnames) }
  /* DWARF 1.1 and DWARF 2.  */
  .debug_aranges  0 : { *(.debug_aranges) }
  .debug_pubnames 0 : { *(.debug_pubnames) }
  /* DWARF 2.  */
  .debug_info     0 : { *(.debug_info .gnu.linkonce.wi.*) }
  .debug_abbrev   0 : { *(.debug_abbrev) }
  .debug_line     0 : { *(.debug_line .debug_line.* .debug_line_end) }
  .debug_frame    0 : { *(.debug_frame) }
  .debug_str      0 : { *(.debug_str) }
  .debug_loc      0 : { *(.debug_loc) }
  .debug_macinfo  0 : { *(.debug_macinfo) }
  /* SGI/MIPS DWARF 2 extensions.  */
  .debug_weaknames 0 : { *(.debug_weaknames) }
  .debug_funcnames 0 : { *(.debug_funcnames) }
  .debug_typenames 0 : { *(.debug_typenames) }
  .debug_varnames  0 : { *(.debug_varnames) }
  /* DWARF 3.  */
  .debug_pubtypes 0 : { *(.debug_pubtypes) }
  .debug_ranges   0 : { *(.debug_ranges) }
  /* DWARF 5.  */
  .debug_addr     0 : { *(.debug_addr) }
  .debug_line_str 0 : { *(.debug_line_str) }
  .debug_loclists 0 : { *(.debug_loclists) }
  .debug_macro    0 : { *(.debug_macro) }
  .debug_names    0 : { *(.debug_names) }
  .debug_rnglists 0 : { *(.debug_rnglists) }
  .debug_str_offsets 0 : { *(.debug_str_offsets) }
  .debug_sup      0 : { *(.debug_sup) }
  .gnu.attributes 0 : { KEEP (*(.gnu.attributes)) }
  /DISCARD/ : { *(.note.GNU-stack) *(.gnu_debuglink) *(.gnu.lto_*) }
}


==================================================
ld: mode elf_x86_64
attempt to open /usr/local/lib/x86_64-linux-gnu/libmpi_usempif08.so failed
attempt to open /usr/local/lib/x86_64-linux-gnu/libmpi_usempif08.a failed
attempt to open /lib/x86_64-linux-gnu/libmpi_usempif08.so succeeded
/lib/x86_64-linux-gnu/libmpi_usempif08.so
libmpi_mpifh.so.40 needed by /lib/x86_64-linux-gnu/libmpi_usempif08.so
attempt to open /build/openmpi-RCkqwI/openmpi-4.1.2/debian/build-gfortran/ompi/mpi/fortran/mpif-h/.libs/libmpi_mpifh.so.40 failed
attempt to open /build/openmpi-RCkqwI/openmpi-4.1.2/debian/build-gfortran/ompi/.libs/libmpi_mpifh.so.40 failed
attempt to open /usr/lib/x86_64-linux-gnu/openmpi/lib/libmpi_mpifh.so.40 failed
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libmpi_mpifh.so.40 failed
attempt to open /usr/local/lib/libmpi_mpifh.so.40 failed
found libmpi_mpifh.so.40 at /usr/lib/x86_64-linux-gnu/libmpi_mpifh.so.40
libmpi.so.40 needed by /lib/x86_64-linux-gnu/libmpi_usempif08.so
attempt to open /build/openmpi-RCkqwI/openmpi-4.1.2/debian/build-gfortran/ompi/mpi/fortran/mpif-h/.libs/libmpi.so.40 failed
attempt to open /build/openmpi-RCkqwI/openmpi-4.1.2/debian/build-gfortran/ompi/.libs/libmpi.so.40 failed
attempt to open /usr/lib/x86_64-linux-gnu/openmpi/lib/libmpi.so.40 failed
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libmpi.so.40 failed
attempt to open /usr/local/lib/libmpi.so.40 failed
found libmpi.so.40 at /usr/lib/x86_64-linux-gnu/libmpi.so.40
libc.so.6 needed by /lib/x86_64-linux-gnu/libmpi_usempif08.so
attempt to open /build/openmpi-RCkqwI/openmpi-4.1.2/debian/build-gfortran/ompi/mpi/fortran/mpif-h/.libs/libc.so.6 failed
attempt to open /build/openmpi-RCkqwI/openmpi-4.1.2/debian/build-gfortran/ompi/.libs/libc.so.6 failed
attempt to open /usr/lib/x86_64-linux-gnu/openmpi/lib/libc.so.6 failed
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libc.so.6 failed
attempt to open /usr/local/lib/libc.so.6 failed
attempt to open /usr/lib/x86_64-linux-gnu/fortran/gfortran/libc.so.6 failed
attempt to open /usr/lib/x86_64-linux-gnu/openmpi/lib/libc.so.6 failed
attempt to open /usr/local/lib/x86_64-linux-gnu/libc.so.6 failed
attempt to open /usr/local/lib/x86_64-linux-gnu/libc.so.6 failed
attempt to open /usr/lib/x86_64-linux-gnu64/libc.so.6 failed
attempt to open /usr/local/lib64/libc.so.6 failed
attempt to open /lib64/libc.so.6 failed
attempt to open /usr/lib64/libc.so.6 failed
attempt to open /usr/local/lib/libc.so.6 failed
attempt to open /lib/libc.so.6 failed
attempt to open /usr/lib/libc.so.6 failed
attempt to open /usr/x86_64-linux-gnu/lib64/libc.so.6 failed
attempt to open /usr/x86_64-linux-gnu/lib/libc.so.6 failed
attempt to open /build/openmpi-RCkqwI/openmpi-4.1.2/debian/build-gfortran/ompi/mpi/fortran/mpif-h/.libs/libc.so.6 failed
attempt to open /build/openmpi-RCkqwI/openmpi-4.1.2/debian/build-gfortran/ompi/.libs/libc.so.6 failed
attempt to open /usr/lib/x86_64-linux-gnu/openmpi/lib/libc.so.6 failed
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libc.so.6 failed
attempt to open /usr/local/lib/libc.so.6 failed
found libc.so.6 at /usr/lib/x86_64-linux-gnu/libc.so.6
libopen-pal.so.40 needed by /usr/lib/x86_64-linux-gnu/libmpi_mpifh.so.40
attempt to open /build/openmpi-RCkqwI/openmpi-4.1.2/debian/build-gfortran/ompi/.libs/libopen-pal.so.40 failed
attempt to open /build/openmpi-RCkqwI/openmpi-4.1.2/debian/build-gfortran/opal/.libs/libopen-pal.so.40 failed
attempt to open /usr/lib/x86_64-linux-gnu/openmpi/lib/libopen-pal.so.40 failed
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libopen-pal.so.40 failed
attempt to open /usr/local/lib/libopen-pal.so.40 failed
found libopen-pal.so.40 at /usr/lib/x86_64-linux-gnu/libopen-pal.so.40
libopen-rte.so.40 needed by /usr/lib/x86_64-linux-gnu/libmpi.so.40
attempt to open /usr/lib/x86_64-linux-gnu/openmpi/lib/libopen-rte.so.40 failed
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libopen-rte.so.40 failed
attempt to open /usr/local/lib/libopen-rte.so.40 failed
found libopen-rte.so.40 at /usr/lib/x86_64-linux-gnu/libopen-rte.so.40
libm.so.6 needed by /usr/lib/x86_64-linux-gnu/libmpi.so.40
attempt to open /usr/lib/x86_64-linux-gnu/openmpi/lib/libm.so.6 failed
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libm.so.6 failed
attempt to open /usr/local/lib/libm.so.6 failed
found libm.so.6 at /usr/lib/x86_64-linux-gnu/libm.so.6
libhwloc.so.15 needed by /usr/lib/x86_64-linux-gnu/libmpi.so.40
attempt to open /usr/lib/x86_64-linux-gnu/openmpi/lib/libhwloc.so.15 failed
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libhwloc.so.15 failed
attempt to open /usr/local/lib/libhwloc.so.15 failed
found libhwloc.so.15 at /usr/lib/x86_64-linux-gnu/libhwloc.so.15
ld-linux-x86-64.so.2 needed by /usr/lib/x86_64-linux-gnu/libc.so.6
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/ld-linux-x86-64.so.2 failed
attempt to open /usr/local/lib/ld-linux-x86-64.so.2 failed
found ld-linux-x86-64.so.2 at /usr/lib/x86_64-linux-gnu/ld-linux-x86-64.so.2
libevent_core-2.1.so.7 needed by /usr/lib/x86_64-linux-gnu/libopen-pal.so.40
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libevent_core-2.1.so.7 failed
attempt to open /usr/local/lib/libevent_core-2.1.so.7 failed
found libevent_core-2.1.so.7 at /usr/lib/x86_64-linux-gnu/libevent_core-2.1.so.7
libevent_pthreads-2.1.so.7 needed by /usr/lib/x86_64-linux-gnu/libopen-pal.so.40
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libevent_pthreads-2.1.so.7 failed
attempt to open /usr/local/lib/libevent_pthreads-2.1.so.7 failed
found libevent_pthreads-2.1.so.7 at /usr/lib/x86_64-linux-gnu/libevent_pthreads-2.1.so.7
libz.so.1 needed by /usr/lib/x86_64-linux-gnu/libopen-rte.so.40
attempt to open /usr/lib/x86_64-linux-gnu/openmpi/lib/libz.so.1 failed
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libz.so.1 failed
attempt to open /usr/local/lib/libz.so.1 failed
found libz.so.1 at /usr/lib/x86_64-linux-gnu/libz.so.1
libudev.so.1 needed by /usr/lib/x86_64-linux-gnu/libhwloc.so.15
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libudev.so.1 failed
attempt to open /usr/local/lib/libudev.so.1 failed
found libudev.so.1 at /usr/lib/x86_64-linux-gnu/libudev.so.1


ld -lmpi_usempif08 --verbose | grep found
found libmpi_mpifh.so.40 at /usr/lib/x86_64-linux-gnu/libmpi_mpifh.so.40
found libmpi.so.40 at /usr/lib/x86_64-linux-gnu/libmpi.so.40
ld: warning: cannot find entry symbol _start; not setting start address
found libc.so.6 at /usr/lib/x86_64-linux-gnu/libc.so.6
found libopen-pal.so.40 at /usr/lib/x86_64-linux-gnu/libopen-pal.so.40
found libopen-rte.so.40 at /usr/lib/x86_64-linux-gnu/libopen-rte.so.40
found libm.so.6 at /usr/lib/x86_64-linux-gnu/libm.so.6
found libhwloc.so.15 at /usr/lib/x86_64-linux-gnu/libhwloc.so.15
found ld-linux-x86-64.so.2 at /usr/lib/x86_64-linux-gnu/ld-linux-x86-64.so.2
found libevent_core-2.1.so.7 at /usr/lib/x86_64-linux-gnu/libevent_core-2.1.so.7
found libevent_pthreads-2.1.so.7 at /usr/lib/x86_64-linux-gnu/libevent_pthreads-2.1.so.7
found libz.so.1 at /usr/lib/x86_64-linux-gnu/libz.so.1
found libudev.so.1 at /usr/lib/x86_64-linux-gnu/libudev.so.1

上面这段信息很长，有很多有价值的信息，如果你只想看关键部分，那么我保留其中的关键内容，来一个精华版的输出信息：

#ld -lmpi_usempif08 --verbose

GNU ld (GNU Binutils for Ubuntu) 2.38
  Supported emulations:
   elf_x86_64
……
using internal linker script:

   notice and this notice are preserved.  */
OUTPUT_FORMAT("elf64-x86-64", "elf64-x86-64",
       "elf64-x86-64")
OUTPUT_ARCH(i386:x86-64)
ENTRY(_start)  # 运行时可执行文件从代码段的 _start 位置开始运行。

# 运行时需从哪些目录找动态库文件
SEARCH_DIR("=/usr/local/lib/x86_64-linux-gnu"); SEARCH_DIR("=/lib/x86_64-linux-gnu"); SEARCH_DIR("=/usr/lib/x86_64-linux-gnu"); SEARCH_DIR("=/usr/lib/x86_64-linux-gnu64"); SEARCH_DIR("=/usr/local/lib64"); SEARCH_DIR("=/lib64"); SEARCH_DIR("=/usr/lib64"); SEARCH_DIR("=/usr/local/lib"); SEARCH_DIR("=/lib"); SEARCH_DIR("=/usr/lib"); SEARCH_DIR("=/usr/x86_64-linux-gnu/lib64"); SEARCH_DIR("=/usr/x86_64-linux-gnu/lib");

# 二进制文件有哪些的代码段、数据段
SECTIONS
{
  PROVIDE (__executable_start = SEGMENT_START("text-segment", 0x400000)); . = SEGMENT_START("text-segment", 0x400000) + SIZEOF_HEADERS;
  .interp         : { *(.interp) }
……
  .rodata         : { *(.rodata .rodata.* .gnu.linkonce.r.*) }

……
  /* Thread Local Storage sections  */
  # 线程本地存储区域
  .tdata   :
   {
     PROVIDE_HIDDEN (__tdata_start = .);
     *(.tdata .tdata.* .gnu.linkonce.td.*)
   }
  .tbss    : { *(.tbss .tbss.* .gnu.linkonce.tb.*) *(.tcommon) }
  .preinit_array    :
  {
    PROVIDE_HIDDEN (__preinit_array_start = .);
    KEEP (*(.preinit_array))
    PROVIDE_HIDDEN (__preinit_array_end = .);
  }
  # 数据区
  .data           :
  {
    *(.data .data.* .gnu.linkonce.d.*)
    SORT(CONSTRUCTORS)
  }
  .data1          : { *(.data1) }
  _edata = .; PROVIDE (edata = .);
  . = .;
  __bss_start = .;

  # BSS区
  .bss            :
  {
   ……
  }
 ……
}

# 下面是本文的重点关注部分
==================================================

# 文件1：逐个目录匹配是否找到被依赖的libmpi_usempif08.so 库文件
ld: mode elf_x86_64
attempt to open /usr/local/lib/x86_64-linux-gnu/libmpi_usempif08.so failed
attempt to open /usr/local/lib/x86_64-linux-gnu/libmpi_usempif08.a failed
attempt to open /lib/x86_64-linux-gnu/libmpi_usempif08.so succeeded
# 找到了 libmpi_usempif08.so 库文件

# 文件2：逐个目录匹配是否找到被依赖的 libmpi_mpifh.so 库文件
libmpi_mpifh.so.40 needed by /lib/x86_64-linux-gnu/libmpi_usempif08.so
attempt to open /build/openmpi-RCkqwI/openmpi-4.1.2/debian/build-gfortran/ompi/mpi/fortran/mpif-h/.libs/libmpi_mpifh.so.40 failed
attempt to open /build/openmpi-RCkqwI/openmpi-4.1.2/debian/build-gfortran/ompi/.libs/libmpi_mpifh.so.40 failed
attempt to open /usr/lib/x86_64-linux-gnu/openmpi/lib/libmpi_mpifh.so.40 failed
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libmpi_mpifh.so.40 failed
attempt to open /usr/local/lib/libmpi_mpifh.so.40 failed
found libmpi_mpifh.so.40 at /usr/lib/x86_64-linux-gnu/libmpi_mpifh.so.40
# 找到了 libmpi_mpifh.so 库文件

# 找 libmpi.so.40
libmpi.so.40 needed by /lib/x86_64-linux-gnu/libmpi_usempif08.so
……
found libmpi.so.40 at /usr/lib/x86_64-linux-gnu/libmpi.so.40

# 找 libc.so.6
libc.so.6 needed by /lib/x86_64-linux-gnu/libmpi_usempif08.so
……
found libc.so.6 at /usr/lib/x86_64-linux-gnu/libc.so.6

# 找 libopen-pal.so.40
libopen-pal.so.40 needed by /usr/lib/x86_64-linux-gnu/libmpi_mpifh.so.40
……
found libopen-pal.so.40 at /usr/lib/x86_64-linux-gnu/libopen-pal.so.40

# 找 libopen-rte.so.40
libopen-rte.so.40 needed by /usr/lib/x86_64-linux-gnu/libmpi.so.40
……
found libopen-rte.so.40 at /usr/lib/x86_64-linux-gnu/libopen-rte.so.40

# 找 libm.so.6
libm.so.6 needed by /usr/lib/x86_64-linux-gnu/libmpi.so.40
……
found libm.so.6 at /usr/lib/x86_64-linux-gnu/libm.so.6
libhwloc.so.15 needed by /usr/lib/x86_64-linux-gnu/libmpi.so.40

# 找 libhwloc.so.15
……略

# 找 libudev.so.1
libudev.so.1 needed by /usr/lib/x86_64-linux-gnu/libhwloc.so.15
attempt to open /usr/lib/x86_64-linux-gnu/libfakeroot/libudev.so.1 failed
attempt to open /usr/local/lib/libudev.so.1 failed
found libudev.so.1 at /usr/lib/x86_64-linux-gnu/libudev.so.1

进一步，我们可以用 grep 过滤只显示 mpi_usempif08 实际找到的库的信息：

#ld -lmpi_usempif08 --verbose | grep found

found libmpi_mpifh.so.40 at /usr/lib/x86_64-linux-gnu/libmpi_mpifh.so.40
found libmpi.so.40 at /usr/lib/x86_64-linux-gnu/libmpi.so.40
ld: warning: cannot find entry symbol _start; not setting start address
found libc.so.6 at /usr/lib/x86_64-linux-gnu/libc.so.6
found libopen-pal.so.40 at /usr/lib/x86_64-linux-gnu/libopen-pal.so.40
found libopen-rte.so.40 at /usr/lib/x86_64-linux-gnu/libopen-rte.so.40
found libm.so.6 at /usr/lib/x86_64-linux-gnu/libm.so.6
found libhwloc.so.15 at /usr/lib/x86_64-linux-gnu/libhwloc.so.15
found ld-linux-x86-64.so.2 at /usr/lib/x86_64-linux-gnu/ld-linux-x86-64.so.2
found libevent_core-2.1.so.7 at /usr/lib/x86_64-linux-gnu/libevent_core-2.1.so.7
found libevent_pthreads-2.1.so.7 at /usr/lib/x86_64-linux-gnu/libevent_pthreads-2.1.so.7
found libz.so.1 at /usr/lib/x86_64-linux-gnu/libz.so.1
found libudev.so.1 at /usr/lib/x86_64-linux-gnu/libudev.so.1

而ldd 与 ld是不同的。ldd是分析linux的运行库的依赖关系、ld是可执行文件链接器常用于C/C++/Fortran等语言代码生成可执行文件的链接阶段。

我们看下 使用 ldd 对同一个动态库所依赖的其他库的分析：

#ldd /usr/lib/x86_64-linux-gnu/libmpi_usempif08.so.40.30.0

 linux-vdso.so.1 (0x00007ffd2f3fd000)
 libmpi_mpifh.so.40 => /usr/lib/x86_64-linux-gnu/libmpi_mpifh.so.40 (0x00007f34366bf000)
 libmpi.so.40 => /usr/lib/x86_64-linux-gnu/libmpi.so.40 (0x00007f3436588000)
 libc.so.6 => /usr/lib/x86_64-linux-gnu/libc.so.6 (0x00007f3436200000)
 libopen-pal.so.40 => /usr/lib/x86_64-linux-gnu/libopen-pal.so.40 (0x00007f34364d5000)
 libopen-rte.so.40 => /usr/lib/x86_64-linux-gnu/libopen-rte.so.40 (0x00007f3436143000)
 libm.so.6 => /usr/lib/x86_64-linux-gnu/libm.so.6 (0x00007f343605c000)
 libhwloc.so.15 => /usr/lib/x86_64-linux-gnu/libhwloc.so.15 (0x00007f3436477000)
 /lib64/ld-linux-x86-64.so.2 (0x00007f343677c000)
 libevent_core-2.1.so.7 => /usr/lib/x86_64-linux-gnu/libevent_core-2.1.so.7 (0x00007f3436442000)
 libevent_pthreads-2.1.so.7 => /usr/lib/x86_64-linux-gnu/libevent_pthreads-2.1.so.7 (0x00007f343643d000)
 libz.so.1 => /usr/lib/x86_64-linux-gnu/libz.so.1 (0x00007f3436040000)
 libudev.so.1 => /usr/lib/x86_64-linux-gnu/libudev.so.1 (0x00007f3436016000)

这里的顺序与ld -lmpi_usempif08 --verbose | grep found 的结果是一致的。

上一篇：Npm 淘宝镜像到期了，尽快切换

下一篇：为 AI 让路，Windows 12 将推迟至 2025 年发布

相关内容

热门资讯

PHP新手之PHP入门 PHP是一种易于学习和使用的服务器端脚本语言。只需要很少的编程知识你就能使用PHP建立一个真正交互的...
网络中立的未来 网络中立性是什... 《牛津词典》中对“网络中立”的解释是“电信运营商应秉持的一种原则，即不考虑来源地提供所有内容和应用的...
各种千兆交换机的数据接口类型详... 千兆交换机有很多值得学习的地方，这里我们主要介绍各种千兆交换机的数据接口类型，作为局域网的主要连接设...
什么是大数据安全 什么是大数据... 在《为什么需要大数据安全分析》一文中，我们已经阐述了一个重要观点，即：安全要素信息呈现出大数据的特征...
如何允许远程连接到MySQL数... [[277004]]【51CTO.com快译】默认情况下，MySQL服务器仅侦听来自localhos...
如何利用交换机和端口设置来管理... 在网络管理中，总是有些人让管理员头疼。下面我们就将介绍一下一个网管员利用交换机以及端口设置等来进行D...
P2P的自白｜我不生产内容，我... 现在一提起P2P，人们就会联想到正在被有关部门“围剿”的互联网理财服务。×租宝事件使得劳...
Intel将Moblin社区控... 本周二，非营利机构Linux基金会宣布，他们将担负起Moblin社区的管理工作，而这之前，Mobli...
施耐德电气数据中心整体解决方案... 近日，全球能效管理专家施耐德电气正式启动大型体验活动“能效中国行——2012卡车巡展”，作为该活动的...
Windows恶意软件20年“... 在Windows的早期年代，病毒游走于系统之间，偶尔删除文件（但被删除的文件几乎都是可恢复的），并弹...
